Worcester Bosch knows its way around a British heating system.

The brand has spent decades warming our homes with boilers, so its move into air source heat pumps was never going to involve throwing a fan onto a metal box and hoping for the best.

Enter the Bosch Compress 5800i AW.

It is compact, Quiet Mark certified and capable of producing flow temperatures up to 75°C. It also uses low-impact R290 refrigerant and comes in three outputs aimed squarely at smaller and medium-sized UK homes.

Very promising.

But heat pumps are not bought on attractive brochures and German engineering alone. They need to be correctly sized, installed and configured around the property.

So, is the Compress 5800i AW genuinely one of the best heat pumps for a UK retrofit - or simply a very quiet box with a reassuring badge on the front?

Let’s take a look.

Ready to make your home more energy-efficient and cut down on your heating bills? Get a heat pump quote today.

Bosch Compress 5800i AW review: the quick verdict

The Bosch Compress 5800i AW is a premium air-to-water heat pump with three particularly strong qualities - it is quiet, compact and unusually capable at higher flow temperatures.

Its published sound-power level starts at just 40dB(A), making it one of the quieter units in its class. Its maximum 75°C flow temperature also gives installers more flexibility when working with existing radiators.

However, that does not mean every radiator can stay or that the system should run at 75°C every day.

The range is limited to 4kW, 5kW and 7kW models, so larger or particularly heat-hungry properties will need to look elsewhere. The guarantee can also vary depending on the installer and how the system is registered.

For an appropriately sized small or medium home, though, the Compress 5800i AW is a very polished bit of kit.

Our scores:

In short: it is the heat-pump equivalent of a Bosch dishwasher.

Quiet, sensible and unlikely to become the most dramatic member of the household.

Key Bosch Compress 5800i AW specifications

Figures vary by model and operating conditions. Always use the final system specification supplied by your installer.

What is the Bosch Compress 5800i AW?

The Compress 5800i AW is an air-to-water monobloc heat pump.

It collects low-level heat from the outdoor air, raises its temperature using a compressor and transfers that energy into the water circulating around your heating system.

Yes, it can still collect heat when the weather is cold.

The garden does not need to be enjoying a private Spanish summer.

As a monobloc system, the complete refrigerant circuit is contained inside the outdoor unit. Water pipes connect it to the equipment indoors, reducing the amount of refrigerant work required inside the property.

A complete installation will normally include:

• The outdoor heat-pump unit

• A wall-mounted indoor hydraulic unit or pre-plumbed cylinder

• A hot-water cylinder

• Heating controls

• Pumps, valves and safety equipment

• Any necessary radiator or pipework upgrades

• Electrical connections

• Potentially a buffer vessel or volumiser, depending on the design

If you currently have a combi boiler, the cylinder is the important bit.

Heat pumps generally store domestic hot water rather than producing unlimited hot water on demand. You therefore need enough indoor space for a suitably sized cylinder.

Bosch offers a slimline 180-litre option as well as 210-litre and 250-litre cylinders, which should make the system easier to accommodate than some bulkier packages.

Bosch Compress 5800i AW sizes

The range consists of three models:

Those applications are deliberately rough.

A heat pump should be selected using a proper room-by-room heat-loss calculation - not the number of bedrooms, the output of your old boiler or an installer having a thoughtful stare at your external wall.

The output available also changes with outdoor and water temperatures. That is why the 7kW model, for example, has a published maximum output of 6.71kW at -7°C air and 35°C flow, but 7.97kW at warmer A7/W35 test conditions.

The name on the box is not the complete design calculation.

The relatively narrow range is one of the 5800i’s main limitations. If your calculated heat loss is comfortably above 7kW, Worcester Bosch and several competing manufacturers offer larger models.

Reliability: 4.5/5

Worcester Bosch is one of the most established heating brands in the UK, with a substantial installer, servicing and spare-parts network.

That matters more than people think.

A heat pump could be efficient enough to warm Windsor Castle using the ambient heat from a lukewarm sandwich, but it is not terribly useful if nobody nearby can repair it.

The Compress 5800i AW also uses a monobloc design, keeping the refrigerant circuit sealed within the outdoor unit. This simplifies the system inside the property and can reduce installation complexity.

Fewer improvised bits of plant-room sculpture is generally welcome.

The small caveat is age.

The 5800i is a comparatively recent product, so it does not yet have the same volume of long-term UK field data as older ranges such as the Mitsubishi Ecodan.

That does not make it unreliable. It simply means some of its reliability score comes from Bosch’s engineering record and support infrastructure rather than fifteen winters of model-specific evidence.

As ever, installation quality is crucial.

A dependable heat pump installed badly is still a badly installed heat pump.

Performance and efficiency: 4.5/5

Bosch publishes MCS seasonal performance figures of approximately:

• 4.53–4.54 SCOP at a 35°C flow temperature

• 3.82–3.96 SCOP at 45°C

• 3.03–3.29 SCOP at 55°C

A SCOP of 4.54 means the heat pump can theoretically deliver around 4.54 units of heat for every unit of electricity consumed across the relevant test season.

That is an excellent figure.

It is not, however, a promise that every home will achieve exactly 4.54.

Real-world efficiency depends on:

• Outdoor temperature

• Required flow temperature

• Radiator or underfloor-heating design

• Property heat loss

• Hot-water demand

• Weather compensation

• Defrost cycles

• System balancing

• Installation and commissioning quality

• How the occupants use the heating

The figures also reveal something important: efficiency falls as flow temperature rises.

At 35°C, the Compress 5800i looks extremely efficient. At 55°C, its published SCOP drops closer to three.

That is not a Bosch problem. It is how heat pumps work.

The less temperature lift the compressor has to produce, the more efficiently it can operate.

The 75°C flow temperature

The ability to produce flow temperatures up to 75°C is one of the Compress 5800i AW’s headline features.

It makes the system more flexible for retrofit projects, particularly where an older property already has radiators designed around a boiler.

However, 75°C should be treated as spare capability - not the daily cruising speed.

It is like owning a car capable of 150mph. Reassuring on the specification sheet, but probably not how you should approach the school run.

A good designer will still aim for the lowest practical flow temperature. That could mean upsizing selected radiators, improving insulation or adjusting the heating curve.

The objective is not merely to make the house warm.

It is to make the house warm without the electricity meter developing stage fright.

What does the Bosch Compress 5800i AW cost to run?

Using Ofgem’s average Direct Debit rates for July to September 2026:

• Electricity costs approximately 26.11p per kWh.

• Gas costs approximately 7.33p per kWh.

• At a SCOP of 3.5, useful heat from a heat pump costs roughly 7.5p per kWh.

• At a SCOP of 4, it costs approximately 6.5p per kWh.

• At the published 4.54 low-temperature SCOP, it would cost approximately 5.8p per kWh.

• Useful heat from a 90%-efficient gas boiler costs roughly 8.1p per kWh.

These are simplified calculations and exclude standing charges. Your tariff, regional rates, hot-water demand and actual seasonal efficiency will affect the result.

Running regularly at higher temperatures also changes the picture.

That is why installing a high-temperature heat pump and then forcing it to behave like an old boiler can quickly spoil the economics.

The 5800i can potentially compete very well with gas in an efficient, properly designed home.

It is not guaranteed to reduce every household’s bill.

For more detail, read our guide to heat-pump running and installation costs.

How quiet is the Bosch Compress 5800i AW?

Very quiet, as heat pumps go.

Bosch publishes the following figures:

The range is also Quiet Mark certified.

Sound pressure and sound power are not interchangeable. Sound power describes the acoustic energy produced by the unit, while sound pressure is what may be measured at a particular position and distance.

In normal-person language: the 5800i is impressively quiet, but you will still hear it when standing nearby.

Fan speed, compressor load, defrosting, mounting and surrounding walls can all influence perceived noise. Poor positioning can also reflect sound towards windows or neighbouring properties.

An installer should therefore complete an acoustic assessment rather than simply positioning it wherever the wheelie bins used to live.

For terraces, semis and homes with close neighbours, its low noise output is a genuine advantage.

Controls and smart features

The Compress 5800i AW can connect to Bosch’s HomeCom Easy app using the supplied Connect-Key internet gateway.

Depending on the final controls package, homeowners can use the system to:

• Change room temperatures

• Adjust heating and hot-water schedules

• Monitor system operation

• Receive error information

• Control the heating remotely

Bosch also offers compatible wired and wireless room controllers.

The more important feature is weather compensation.

Rather than producing the same flow temperature regardless of conditions, weather compensation adjusts the heating water temperature as the weather changes.

A mild day might only require gently warmed water. A freezing morning requires more.

This helps the heat pump run steadily and efficiently instead of repeatedly charging around like a boiler with somewhere urgent to be.

Bosch also advertises remote system monitoring from its UK team. Its homeowner literature notes that this monitoring requires the internet gateway and a Wi-Fi connection, and may end automatically after 12 months.

Check what monitoring, controls and connectivity are included in your quotation.

“App compatible” and “everything required for app control is fitted and commissioned” are not always the same sentence.

R290 refrigerant: why it matters

The Compress 5800i AW uses R290 refrigerant, better known as propane.

Before anyone starts picturing a patio heater connected to the radiators, the refrigerant is sealed within the outdoor unit.

R290 has a published Global Warming Potential of just three, substantially lower than commonly used synthetic refrigerants such as R32.

It also has useful thermodynamic properties at higher temperatures, helping the 5800i achieve its maximum 75°C flow temperature.

There are safety considerations.

R290 is flammable, so the outdoor unit must be positioned according to Bosch’s protected-area and clearance requirements. Windows, doors, drains and potential ignition sources can affect where it may be installed.

That is another reason to insist on a detailed site survey.

The result should be a future-conscious refrigerant and a safe installation—not an outdoor unit wedged beneath the kitchen window because the pipe run was slightly more convenient.

Warranty: 4/5

Worcester Bosch’s current guarantee information says heat pumps can receive up to seven years of cover, depending on the installer’s qualifications and position within the manufacturer’s loyalty scheme.

That is competitive, but “up to” is carrying out some fairly heavy lifting.

Before accepting a quotation, confirm:

• The exact guarantee length

• Whether parts, labour and call-outs are included

• Which indoor components are covered

• Whether the cylinder has separate cover

• Who will register the system

• The registration deadline

• Annual servicing requirements

• Whether the guarantee depends on using an accredited installer

Some retailers list the standard product cover as two years, with longer terms available through qualifying installers.

Do not rely on a logo in a brochure.

Ask for the included guarantee period in writing.

Bosch Compress 5800i AW cost: 4/5

A complete Worcester Bosch heat-pump installation will typically cost approximately £8,000–£15,000 before grants.

The outdoor unit itself is only part of the bill. The final price can include:

• The indoor unit or pre-plumbed cylinder

• Hot-water storage

• Controls and internet gateway

• Pumps, valves and system components

• New or upgraded radiators

• Pipework alterations

• Electrical work

• Concrete base or mounting equipment

• System cleaning and flushing

• Heat-loss calculations and system design

• Commissioning and certification

• Removal of the existing heating system

A straightforward 4kW or 5kW installation in a relatively heat-pump-ready property may sit towards the lower end.

A 7kW system requiring a cylinder, radiator changes and substantial pipework can cost considerably more.

The 5800i is not a bargain-basement heat pump.

Its low noise, compact indoor options, high-temperature capability and established manufacturer support go some way towards justifying the price.

Boiler Upgrade Scheme grants

Eligible homeowners in England and Wales can currently receive £7,500 towards an air-to-water heat pump through the Boiler Upgrade Scheme.

Until March 2027, the grant increases to £9,000 where both of the following apply:

• The property is not connected to mains gas.

• The heat pump is replacing an oil or LPG heating system.

The scheme is installer-led. An MCS-certified installer applies for the grant and deducts the approved amount from your quotation.

Bosch says the Compress 5800i can also form part of a hybrid heating system alongside a boiler. However, hybrid systems are not eligible for the Boiler Upgrade Scheme.

Installation and space requirements

The Compress 5800i outdoor unit measures:

• 1,100mm wide

• 800mm high

• 540mm deep

• 143kg

That is relatively compact, but it is not something two people casually pop beside the shed during their lunch break.

The published standard clearances are substantial:

• 2,000mm at the front

• 1,000mm at the sides

• 400mm at the rear

Bosch allows some clearances to be reduced under specified configurations, but the installer must also account for airflow, servicing, acoustics and the R290 protected area.

The sleek casing may occupy 1.1 metres of wall.

The compliant installation space can occupy rather more.

Indoor options include:

The slimline cylinder is useful for homes short on cupboard space, although cylinder size should ultimately be chosen around hot-water demand - not whichever one fits most elegantly beside the towels.

A proper installation should include:

• A room-by-room heat-loss calculation

• Radiator and pipework assessment

• Outdoor siting and noise calculations

• Hot-water-cylinder sizing

• Electrical assessment

• System design temperatures

• Installation and cleaning

• Weather-compensation setup

• Commissioning and homeowner handover

• MCS, grant and guarantee registration

If the survey consists mainly of asking how many bedrooms you have, somebody has confused heating design with a Rightmove filter.

Bosch Compress 5800i AW pros and cons

Pros

• Exceptionally low published noise levels

• Quiet Mark certified

• Maximum flow temperature up to 75°C

• Excellent SCOP figures at lower flow temperatures

• A+++ energy rating at 35°C

• Low-GWP R290 refrigerant

• Compact single-fan outdoor design

• 230V single-phase models

• Wall-mounted and pre-plumbed indoor options

• Slimline 180-litre cylinder available

• HomeCom Easy app connectivity

• Weather compensation

• Remote monitoring capability

• Up to seven years of guarantee cover

• Established Worcester Bosch UK support network

• Suitable for new-build and retrofit projects

• Eligible installations can access the Boiler Upgrade Scheme

Cons

• Limited to 4kW, 5kW and 7kW models

• Unsuitable for many larger or high-heat-loss properties

• Premium purchase price

• Exact guarantee period depends on installer conditions

• Usually requires indoor space for a hot-water cylinder

• Some properties will still need radiator upgrades

• Efficiency falls when higher flow temperatures are used

• R290 siting rules can restrict installation positions

• The outdoor unit weighs 143kg

• Required clearances may undermine the “compact” claim on tight sites

• Remote monitoring may be time-limited

• Less long-term model-specific evidence than older heat-pump ranges

Bosch Compress 5800i AW vs the competition

The Bosch’s biggest differentiator is its combination of compact dimensions and very low published noise.

The Vaillant aroTHERM plus offers a broader choice of outputs and a higher headline SCOP. Mitsubishi’s R290 Ecodan range extends further into larger homes, while Samsung offers capacities up to 16kW and deeper smart-home integration.

For a home needing 4kW–7kW, the Bosch is highly competitive.

For a property needing 10kW, the discussion ends rather quickly.

The best heat pump is not automatically the model with the highest specification. It is the one that matches the property’s heat loss, emitter design, available space and local support.

Who is the Bosch Compress 5800i AW best for?

The Compress 5800i AW should make your shortlist if:

• Your calculated heat loss falls within the 4kW–7kW range.

• You own a small or medium-sized home.

• Noise is an important consideration.

• Your property has close neighbours.

• You want a heat pump suitable for an existing radiator system.

• You have room for a hot-water cylinder.

• You want app-based controls and weather compensation.

• You prefer an established UK heating brand.

• You value a neat pre-plumbed indoor solution.

• You are replacing oil, LPG or direct electric heating.

• You want to use the Boiler Upgrade Scheme.

Who might want to look elsewhere?

Another heat pump may be a better fit if:

• Your design heat loss is above the 5800i’s available output.

• You cannot accommodate a hot-water cylinder.

• Outdoor clearances or R290 restrictions rule out a suitable location.

• Your main priority is the lowest possible purchase price.

• You want a longer unconditional standard guarantee.

• You need a large-capacity heat pump for a substantial detached home.

• You are expecting boiler-style bursts of heat rather than steady operation.

• You do not want to make any necessary radiator or pipework changes.

The Heatable verdict

The Bosch Compress 5800i AW is one of the most convincing compact heat pumps currently available for smaller and medium-sized UK homes.

It is extremely quiet, smartly packaged and capable of reaching flow temperatures up to 75°C. Its low-temperature SCOP figures are strong, while the R290 refrigerant and A+++ rating give it solid environmental credentials.

The pre-plumbed cylinder options are also genuinely useful.

The biggest weakness is its limited capacity range. With no model above 7kW, the 5800i simply will not suit every property. Its higher-temperature capability should not be used as an excuse to skip proper radiator and system design either.

There is also the usual guarantee homework to complete. “Up to seven years” needs turning into a specific written promise before anybody signs the quotation.

But in the right home?

This is an excellent heat pump.

Our final score: 4.5 out of 5

Get the design temperatures, sizing and installation right, and the Bosch Compress 5800i AW should spend most of its life doing something British heating equipment has not traditionally been famous for:

Keeping quiet.

Very considerate.

Next Steps For Your Heat Pump Journey:

When planning to install a heat pump for your home, there are several important factors to consider. Make sure to refer to the following guides to help you make informed decisions:

• What is the Boiler Upgrade Scheme?

• Is my home suitable for a heat pump?

• How much do heat pumps cost?

• Best heat pump brands.

• What size heat pump do you need?

• Aira heat pump review.

To dive deeper into these topics, head over to our advice section or check out our YouTube channel to learn more.

Get A Quote From Us Today

Without boasting, get your new heat pump quote and buy from us, here’s why:

• Gas Safe installation within 24 hours.

• Thousands of satisfied customers with an average score of 4.9 on Trustpilot, surpassing the market leader.

• Which? Trusted Trader: Heatable is proudly recognised as a Which? Trusted Trader.

• Flexible payment options, including interest-free finance.

• Up to 12-year guarantee on selected heat pumps.

• Fixed price guarantee: No hidden costs.

• Save your quote and decide later.

• Get an instant fixed price on a heat pump, here.

Heat Happy.
